Главная Каталог запчастей Запчасти для промышленных швейных машин Juki LBH-781 JUKI 15. Thread tension components

15. Thread tension components

Вернуться к выбору схем

Выбор схемы:

15. Thread tension components

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

73

100%

№

Артикул Артикул и наименование

Наименование

40009325 tension release link

SD0640391TP hinge screw d= 6.35 h= 3.9

B3152781000 tension release lever

SS6660712TP screw 1/4-40 l= 7.0

SD0640241SP hinge screw d= 6.35 h= 2.4

40009165 blocking link

SD0640391TP hinge screw d= 6.35 h= 3.9

B2056781000 blocking arm spring

SD0790311TP hinge screw d= 7.94 h= 3.1

40008611 blocking arm

40008609 blocking arm bracket

NS6110310SP nut 11/64-40

NS6120310SP nut 3/16-28

B3116771000 tension release lever

SS7621040SP screw 3/16-32 l= 9.5

CS079101DSH thrust collar asm. d=7.94 w=10

SS8110520TP screw 11/64-40 l= 4.5

40009327 tension release lever crank as

40009328 tension release crank no.2

SD0500301SP hinge screw d= 5 h= 3

NS6090310SP nut 9/64-40

40009329 tension release rod

RO095200100 rubber ring

B310777100B tension release lever collar n

SS6111610SP screw 11/64-40 l=16

B31107710A0 tension controller no.2 asm.

11956703 thread tension knob, red

B3112704000 tension spring bushing

B3101804000 tension spring, red

B3107804000 thread tension disk presser

B3126012000 thread tension disk

B3111761000 tension post no.3

B3112761000 thread take-up spring

B3110771000 tension post socket

SS8090670SP screw 9/64-40 l= 5.5

B3106771000 tension release lever shaft

SS7110840SP screw 11/64-40 l=7.8

B3120771000 thread pulling wire

B31037710A0 tension controller no. 1 asm.

11956703 thread tension knob, red

B3112704000 tension spring bushing

B2017372000 tension spring no.1

B3107804000 thread tension disk presser

B3126012000 thread tension disk

B3103761000 tension release pin no.2

B2019372000 tension post no.2

NS6160520SP nut 1/4-24

B31027710A0 tension release arm asm.

SS9660940TP screw 1/4-40 l=8.5

SS4150715SP screw 15/64-28 l=7

B1111232000 thread guide plate

B3117771000 spring

CS0790720TH thrust collar asm.

SS7090720SM screw 9/64-40 l=7

40009339 tension release rod

PS0300182KF spring pin 3x18

SS4110715SP screw 11/64-40 l=7

22920706 two eyelet

40009037 take-up thread guide

SS7090710SP screw 9/64-40 l= 6.8

40009340 needle bar thread guide

SS7110840SP screw 11/64-40 l=7.8

B3118771000 tension thread guide, no.2

B3114771000 thread guide

NS6090310SP nut 9/64-40

B3118552D00 tension release pin, no.2

B3118552H00 thread release pin
