11. Feed cam & tripping segment components

Вернуться к выбору схем

Выбор схемы:

11. Feed cam & tripping segment components

Как искать запчасти?

1

2

2

3

3

4

4

5

5

6

7

7

8

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

34

35

36

36

36

36

37

37

37

37

38

39

40

41

42

42

43

44

45

46

46

100%

№

Артикул Артикул и наименование

Наименование

B2935761000 spur gear (152)

B29167610A0 spur gear bushing asm.

B2917761000 spur gear bushing pin

SS7120910TP screw 3/16-28 l=9

B29137610A0 clutch collar asm.

SS8660610TP screw 1/4-40 l=6

SS8660410SP screw 1/4-40 l= 4.2

40009314 clutch collar

B2919761000 feed cam driving worm wheel

40009316 feed cam driving worm wheel sh

B3542771000 oil felt

26107201 cam driving shaft

B2934761000 spur gear (123)

B2915761B00 handle crank bevel gear, left

B2915761AA0 handle crank bevel gear asm.,

SS8660610TP screw 1/4-40 l=6

CS111101DSH thrust collar asm. d=11.11 w=1

SS8660530TP screw 1/4-40 l= 4.5

40009318 handle crank shaft

B2923761000 handle crank

40009319 handle crank

SS8150510TP screw 15/64-28 l= 4.7

SS8620610SP screw 3/16-32 l=6

40009320 handle

40009321 handle shaft

B29107610A0 feed cam driving gear asm.

SS8660610TP screw 1/4-40 l=6

NM6120001CP nut m12

B2909761000 thrust washer

40009312 feed cam shaft

B290177100C feed cam

WP0982616SP washer 9.8x24.0x2.6

SS9241513CP screw 3/8-18 l=15

SS7111410TP screw 11/64-40 l=14

B2902761B00 bar tripping segment no.2 (b)

WP0480856SP washer 4.8x8.4x0.8

SS6111610SP screw 11/64-40 l=16

B2904771000 knife tripping segment

40009309 tension release tripping segme

40009310 tension release tripping segme

B2906761B00 tripping segment no.2, under 8

26100909 bearing stud cam no.1

B2903761B00 bar tripping segment no.2 (b)

26100800 low-speed com

B2914761000 clutch spring
