9. Bobbin thread trimmer components

Вернуться к выбору схем

Выбор схемы:

9. Bobbin thread trimmer components

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

100%

№

Артикул Артикул и наименование

Наименование

B24017710A0 needle plate asm.

B2402771000 needle plate

SS2090510SP screw 9/64-40 l=5

B24017710B0 throat plate base asm.

B24067710A0 bobbin thread trimmer blade as

SS5090320SP screw 9/64-40 l= 3.2

B2408771000A counter knife

SS4080310SP 00040801

B2404771000 bobbin thread trimmer lever

SS7110570SP screw 11/64-40 l= 4.8

WP0451016SP washer 4.5x20x1

B2405771000 bobbin thread puller

SS6090440SP screw 9/64-40 l= 4.0

SS6090630TP screw 9/64-40 l=6

40009218 bobbin picker stopper

B2416771000 presser plate

SS7110840SP screw 11/64-40 l=7.8

40009220 bobbin picker presser plate

SD0630272SP hinge screw

B2422771000 bobbin picker bracket

SS7090620TP screw 9/64-40 l=6.1

40009217 bobbin picker bracket shaft

40009215 bobbin winder trip latch

40009223 safety stopper

SS6110610TP screw 11/64-40 l=6

40009222 presser plate adjusting spring

40009219 presser plate mounting base

40009214 bobbin thread trimmer link

NS6120310SP nut 3/16-28

40009221 presser plate adjusting screw

SD0640321SP hinge screw d= 6.35 h= 3.2

SD0640602SP hinge screw d= 6.35 h= 6.0

B2417771000 bobbin thread guide

SS4090415SP screw 9/64-40 l=4

NS6150310SP nut 15/64-28

SD0790602SP hinge screw d= 7.94 h= 6

40009210 bobbin thread trimmer driving

NS6150310SP nut 15/64-28

SS7110570SP screw 11/64-40 l= 4.8

40009211 connecting link

B2414761000 stop screw

NS6680320SP nut 9/32-28

B2416761000 hing stud

SS8150822TP screw 15/64-28 l=8

40009209 bobbin thread trimmer driving

SD0790641SP hinge screw d= 7.94 h= 6.4

B2412047000 ball screw

SS7110710SP screw 11/64-40 l=7
