3. Main shaft components

Вернуться к выбору схем

Выбор схемы:

3. Main shaft components

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

100%

№

Артикул Артикул и наименование

Наименование

B1404761000 hinge stud

SS8150822TP screw 15/64-28 l=8

CQ252000000 oil wick

40009087 oil wick holder

SS7090510SP screw 9/64-40 l= 4.6

B1147125000 oil wick snap ring

BP600000000 vinyl pipe

40008610 main shaft

CM500300001 direction label

B1901761BA0 thread take-up lever asm., cer

B19017610A0 thread take-up lever asm.

B1203771000 needle bar crank

B1204761000 needle bar crank connecting ro

B1905541B00 needle bearing

B1903552000 left screw

B2615232000 oil felt washer

B1223771000 needle rod crank washer

40009048 counterweight asm.

SS8681650TP screw 9/32-28 l=16

SS8660512TP screw 1/4-40 l=5

SS7681750TP screw 9/32-28 l=16.5

B1204771000A bushing, front

B1203012000 oil felt

B3541012000 oil wick

LBH-781.26100701 knife bar driving connecting

B2722761000 knife bar driving eccentric

SS8660810TP screw 1/4-40 l=8

B1208552000A oil seal

26104703 main shaft bushing,intermediat

SS8150822TP screw 15/64-28 l=8

B29207610A0 worm asm.

SS8660610TP screw 1/4-40 l=6

CS147121BSH thrust collar asm. d=14.72 w=1

SS8660530TP screw 1/4-40 l= 4.5

40009400 main shaft thrust collar asm.

SS8660530TP screw 1/4-40 l= 4.5

B12567810A0A main shaft rear bushing asm.

B1256781000A upper shaft rear metal

B1208552000A oil seal

40009426 bearing retainer

SS7110910TP screw 11/64-40 l= 8.5

B1257781000 felt b

40009427 loose pulley

RC3000001KP retaining ring 30

40009462 felt-b guide

SB130000100 bearing d=30x55

SS8150822TP screw 15/64-28 l=8

B1254781000 main shaft thrust seel

SS7090410SP screw 9/64-40 l= 3.5

B1227771000 gasket

B1220771000 thrust washer a

B1225771000.1 bearing

SS7660510SP screw 1/4-40 l=5.0

SS8660512TP screw 1/4-40 l=5

40009049 driving pulley

B122477100C screw (c)

B1231771000 stop cam pressure spring

40009070 stop-motion cam pin slide bloc

B1212232000 bakelite segment

40009069 stop-motion cam position pin

B1208771000 stop motion cam

40009058 stop motion cam presser plate

SS7110710SP screw 11/64-40 l=7

CQ252000000 oil wick

B3541012000 oil wick

B125578100B washer b

B1229771000 main shaft thrust washer (c)
