5. Presser bar & work clamp carrier components

Вернуться к выбору схем

Выбор схемы:

5. Presser bar & work clamp carrier components

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

100%

№

Артикул Артикул и наименование

Наименование

40009129 presser spring regulator

40009119 presser bar

B1507761000 presser spring

B1506761000 presser bar guide bracket

SS7111310SP screw 11/64-40 l=12.8

B15057610A0 presser bar position bracket a

SS8660810TP screw 1/4-40 l=8

40009121 sleeve

40009123 slide roller

B1503771000 connecting pin

B1502771AA0A bracket asm.

40009131 bracket

40009132 finger guard

SS7090710SP screw 9/64-40 l= 6.8

SS4091520SP screw 9/64-40 l=15

SS7110710SP screw 11/64-40 l=7

40009122 work clamp bracket

SS2110920TP screw 11/64-40 l=8.5

SS7110840SP screw 11/64-40 l=7.8

SS7110840SP screw 11/64-40 l=7.8

40009190 needle thread trimmer guide (a

B15527810A0A presser foot asm.

B15117710A0B presser foor asm.

B1511771000B presser foot

B1509761000 work clamp check spring

B151077100B work clamp check spring set pi

B1512761000 work clamp check holder spring

B1552781000A work clamp check

SS6060210SP screw 3/32-56 l= 1.9

B1508771A00 work clamp check, knit good

B1613771A00A work clamp carrier

40009445 work clamp carrier

B16077630A0 bracket cover

SS5110810SP screw 11/64-40 l=8

B16117710A0 work clamp arm bracket asm.

SS6151440SP screw 15/64-28 l=14

B1606763000 work clamp carrier bracket pit

SD0870601SP hinge screw d= 8.73 h= 6.0

26105908.1 work clamp arm slide rod

B1612763000 work clamp carier bracket guid

SS6111010TP screw 11/64-40 l= 9.5

B1551781000 work clamp

B1517761000 connecting pin

SS7090920SP screw 9/64-40 l= 8.5

B1516771000 bearing arm

SS8150710SP screw 15/64-28 l=7

SS8150920SP set-screw

40009137 length regulating hinge stud

40009134 length regulating shaft guide

NS6150310SP nut 15/64-28

51

Под заказ Рычаг на механизм регулировки длины петли (арт. B16037630A0)

40009144 length regulating shaft crank

SM6061602TP screw m6 l=16

WP0650876SD washer 6.5x13x0.8

40009146 bell crank roller stud

40009143 roller

SD0790203SP hinge screw d=7.94 h=2

NS6150310SP nut 15/64-28

40009178 needle thread trimmer guide (b #1,#2)
