8. Needle thread trimmer components

Вернуться к выбору схем

Выбор схемы:

8. Needle thread trimmer components

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

24

25

26

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

100%

№

Артикул Артикул и наименование

Наименование

B20017710A0 needle thread trimmer asm.

B2001771000 needle thread trimmer,lower

B2005761000 position pin

B20027710A0 needle thread trimmer, upper

B2003771000 needle thread presser spring

SD0400191TP hinge screw d=4 h=1.9

SS7110510SP screw 11/64-40 l=5

SS4150715SP screw 15/64-28 l=7

40009179 needle thread trimmer shaft gu

B20637810B0A thread trimmer holder asm.

SM8061002TP screw m6 l=10

40009170 thread trimmer holder asm.

SM8061002TP screw m6 l=10

40008607 limitting plate

SS7110840SP screw 11/64-40 l=7.8

40009168 draiving cam spring

40009169 draiving cam spring axle

SD0450401SP hinge screw d= 4.5 h= 4

40008608 driving cam instaling plate

SD0790303SP hinge screw d= 7.94 h= 3.0

40009167 differential feed cam

SS7090710SP screw 9/64-40 l= 6.8

PS0300102K0 spring pin 3.0x10

B2010771000 bracket

B2052781000 thread trimmer spring a

SS6621212TP screw 3/16-32 l=12.0

LBH-781.40009330 thread shaft guide base

LBH-781.40009164 thread trimmer spring b

B20077710B0 needle thread trimmer shaft as

40009193 needle thread trimmer shaft

26023200 cam roll

SS6080610TP screw 1/8-44 l=6

40009196 suspension screw

40009186 latch presser arm

SS7090710SP screw 9/64-40 l= 6.8

40009191 spacer

40009181 locking bracket latch asm.

SS7110840SP screw 11/64-40 l=7.8

B2030771000 thread trimming shaft segment

SD0641003SP hinge screw d=6.35 h=10

NS6110310SP nut 11/64-40

NS6080210SP nut 1/8-44

NS6080340SP nut 1/8-44

40009188 roller

B2032771000 stud

SS7110840SP screw 11/64-40 l=7.8

40009160 thread trimmer holder asm.
