10. Knife bar components

Вернуться к выбору схем

Выбор схемы:

10. Knife bar components

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

100%

№

Артикул Артикул и наименование

Наименование

40009302 knife stop lever bracket

PS0300182KF spring pin 3x18

SS7110740TP screw 11/64-40 l=7

B2729771000 knife stop lever

SS6110420TP screw 11/64-40 l=4.8

40009300 knife stop lever hinge stud

B2731761000 thread check wire

SS7110840SP screw 11/64-40 l=7.8

B2702771000A knife bar

40009280 knife rod guide plate a

SS7110710SP screw 11/64-40 l=7

40009290 hinge stud

B2706761000 knife bar connecting link

B2705761000 hinge screw

NS6660430SP nut 1/4-40

40009284 knife bar positioning bracket

SS7110840SP screw 11/64-40 l=7.8

B2701761000 knife holder

B2740771000 thrust washer

SM6061202TP screw m6 l=12

B2702047L00A knife 1/2

WP0501016SD washer 5x10.5x1

SS7620750SP screw 3/16-32 l= 6.5

B2751781000 knife bar driving lever

SS7110810SP screw 11/64-40 l= 8.0

B2710771000 spring

SD0550501SP hinge screw d=5.5 h=5

40009264 knife bar stopper asm.

40009265 knife bar stopper

40009266 stopper bush

NS6740510SP nut 3/8-28

SD0790201SD hinge screw d=7.9 h=2.0

NS6700540SP nut 5/16-24

40009294 knife bar driving crank nut

B2718761000 tension spring

SS7161040SP screw 1/4-24 l= 9.5

40009291 knife bar driving crank

CQ252000000 oil wick

B3537122000 oil wick holder

SS4090610SP screw 9/64-40 l=6

SM6062002TP screw m6 l=20

SD1110905TH hinge screw d=11.11 h= 9.0

26105809 knife bar driving crank shaft

40009304 spacer

40009441 knife bar driving lever bell c

SS8111610SP screw 11/64-40 l=15.5

NS6110310SP nut 11/64-40

SD1110905TH hinge screw d=11.11 h= 9.0

40009277 hook pin nut

40009278 hook pin

B2416761000 hing stud

SS8150822TP screw 15/64-28 l=8

B2725761000 tension spring

B2724761000 ratchet pawl (b)

B27237610A0A hook differential click a asm.

B2723761000A hook differential click a

10120004 spring suspension

B1110280000 thread cutting link spring rac

B2726761000A tension spring

SD0530221SP hinge screw d= 5.3 h= 2.2

40009270 driving rod

40009299 tension spring

40009305 suspension screw

40009274 finger

SS7090710SP screw 9/64-40 l= 6.8

40009303 positioning pin (b)

NS6200520SP nut 5/16-18

B2709771000 knife bar driving lever shaft
