4. Feed Adjust Mechanism Components

Вернуться к выбору схем

Выбор схемы:

4. Feed Adjust Mechanism Components

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

10

11

12

13

14

15

16

17

18

19

20

21

22

24

26

27

28

29

30

31

32

33

34

37

38

39

40

41

42

43

44

44

45

46

100%

№

Артикул Артикул и наименование

Наименование

02-121A-1230 T Hrust Collar

11-80160710-01 Screw Sm1/4x40 L=7

06-029A-640L Feed Regulator Shaft Bushing

11-80151010-01 Screw Sm15/64x28 L=10

11-80150812-01 Screw Sm15/64x28 L=8

1300-04-06 Reverse Shaft For Feed Regulator Shaft

1300-04-07 Connecting Pin

1300-04-08 Feed Regulator Shaft

1300-04-09 Slide Block Guide Plate

11-40110825-01 Screw Sm11/64x40 L=8

31-14624000-09 O-rings

1302-04-12 Hinge Pin For Regulatop

1300-04-13 Bracket For Spring

11-80150812-01 Screw Sm15/64x28 L=8

1300-04-15 Washer

24-04000000-08 Retaining Ring d. 4

1300-04-17 Connecting Rod For Feed Regulator Shaft

1300-04-18 B/t Solenoid Crank

1300-04-19 Feed Link Pin

1300-04-21B Feed Regulator

1300-04-21 Feed Regulator

1300-04-22 Bracket For Spring(small)

1300-04-24 Spring Hook

101-07-06 Plunger Spring

DPN-AA007700 Stopper Pin

1300-04-28 Spring For Feed Regulator

24-07000000-08 Retaining Ring d. 7

31-09624000-09 Rubber Ring

1300-04-31 Feed Regulator Screw

1300-04-32 Feed Link Pin

12-80400512-01 Screw M4 L=5

1300-04-34 Dial

11-70121120-01 Screw Sm3/16x28 L=11

120-03-21 Screw

11-40622025-01 Screw Sm3/16x28 L=20

06-033A-2350 Reverse Feed Control Lever

11-60121420-01 Screw Sm3/16x28 L=15

1300-04-42 Shaft Of Reverse Feed Control Lever

31-07118000-09 Rubber Ring

1300-04-44B Reverse Feed Crank Pin

11-70110820-01 Screw Sm11/64x40 L=8

120-03-27 Spring For Reverse Feed Crank
