3. Feed Mechanism Components

Вернуться к выбору схем

Выбор схемы:

3. Feed Mechanism Components

Как искать запчасти?

1

2

3

4

5

6

7-1

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

21

22

23

24

24

25

26

27

28

29

30

31

31

32

33

34

34

35-1

35

36

37

38

39

40

41

42

42

43

44

44

45

46

47

48

49

50

51

52

53

54

55

56

57

57

58

59

60

100%

№

Артикул Артикул и наименование

Наименование

11-40110625-01 Screw Sm11/64x40 L=6

06-168A-640L Eccentricity Shaft For Feed Bar

120-04-01 Feed Rock Shaft Crank

11-60121420-01 Screw Sm3/16x28 L=15

21-06113102-03 Washer d. 10xd. 6 L = 1.3

11-60080620-01 Screw Sm1/8x44 L=6

1300-03-07 Feed Dog

120-04-03 Feed Bracket

1300-03-09 Feed Lifting Rock Shaft Crank(front)

11-60121420-01 Set Screw Sm3/16x28 L=15

1300-03-11 Pin For (short)

11-40110825-01 Set Screw Sm11/64x40 L=8

1300-03-13 Feed Connecting Rod

1300-03-14 Slide Block Shaft

1300-03-15 Slide Block

11-60150720-01 Set Screw Sm15/64x28 L=7

11-40151525-01 Set Screw Sm15/64x28 L=15

1300-03-18 Feed Rock Shaft Crank(right)

1300-03-19 Hinge Pin

1300-03-20 Feed Rock Shaft

02-013A-3710 Thrust Collar

11-80160510-01 Screw Screw Sm1/4x40 L=5

1300-03-30 Feed Rock Shaft Bushing(front)

25-15000000-08 Snap Ring

122-02-71 Bobbin Case

1222-05-03 Bobbin(aluminum)

11-70111120-01 Rotating Hook Positional Screw Sm11/64x40 L =11

07-013A-1230 Rotating Hook Positional

1222-05-01 Rotating Hook Complete

1300-03-30 Feed Lifting Rock Shaft Bushing

21-15020212-03 Washer

101-05-08 Set Screw

101-05-09 Oil Wick

11-80150510-01 Screw Sm15/64x28 L=5

1300-03-35 Hook Shaft Bushing(front)

07-107A-250A Hook Shaft Bushing(front)

11-80161012-01 Screw Sm1/4x40 L=10

1300-03-37 Thread Trimmer Cam

1300-03-38 Hook Shaft(middle)

1300-03-39 Hook Shaft

11-80110612-01 Screw Sm11/64x40 L=6

101-05-16 Collar For Hook Shaft

1300-03-42 Hook Shaft Bushing(right)

1300-03-43 Feed Lifting Rock Shaft

11-80151310-01 Screw Sm15/64x28 L=13

120-02-64 Plunger

120-02-65 Plunger Spring

120-02-66 Guide Plate

11-60151020-01 Screw Sm15/64x28 L=10

22-06000000-08 Washer

1300-03-50 Feed Lifting Rock Shaft Crank

1300-03-51 Feed Lifting Rock Shaft Crank

11-80151010-01 Screw Sm15/64x28 L=10

11-40110625-01 Screw Sm11/64x40 L=6

120-04-24 Slide Block Pin

1300-03-55 Washer

22-05000000-08 Feed Lifting Rock Shaft Bushing (rear)

1300-03-57 Bushing

11-40621425-01 Screw Sm3/16x32 L=14

1230-09-40 Spacer

11-80150810-01 Screw Sm15/64x28 L=8

1301-03-07 Feed Dog
