Главная Каталог запчастей Запчасти для промышленных швейных машин Aurora A-611 AURORA 1. Frame Components

1. Frame Components

Вернуться к выбору схем

Выбор схемы:

1. Frame Components

Как искать запчасти?

1

1

1

1

2

3

3

4

5

6

6

6

6

7

8

9

10

11

12

13

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

28

29

30

31

32

33

34

35

35

36

37

38-1

38

39

40

41

42-1

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

62

63

100%

№

Артикул Артикул и наименование

Наименование

1

Под заказ Приспособление "Широкий полуторный подгиб" для прямострочных машин G310 SURUCU

1300-01-02 Oli Felt

11-60111020-01 Screw Sm11/64x40 L=10

1300-01-04 Back Cover

1300-01-05 Gasket For Back Cover

120-01-30 Rubber Plug d. 19

13-60113020-02 Upper Thread Guide Pin Nut

1300-01-08 Upper Thread Guide Pin

101-01-14 Model Plate Rivet

1300-01-10B Side Plate

01-129C-640L Side Plate Gasket

120-01-30 Rubber Plug d. 19

11-70090720-02 Screw Sm9/64x40 L=7

114-01-20-02 Rubbet Washer

1-60111120-01 Screw Sm11/64x40 L=11

1302-01-16 Top Cover

1300-01-17 Gasket For Top Cover

1300-01-22 Rubber Plug d. 23

1300-01-19 Rubber Plug d. 29

1300-01-20 Rubber Plug d. 26

1300-01-21 Model Plate

1300-01-22 Rubber Plug d. 22

11-80110612-01 Set Screw Sm11/64x40 L=6

01-021R-1600 Rubber Plug d. 24.6

22-06000000-08 Washer

101-01-15 Bed Leg

409-11-01 Thread Tension Asm No.1

11-70090720-02 Screw Sm9/64x40 L=7

120-01-18 Arm Thread Guide

11-80150710-01 Screw Sm15/64x28 L=7

11-20110850-02 Screw Sm11/64x40 L=5.5

CMB-BJ002400 Connecting Rod

120-01-06 Face Rubber Plug d. 11.8

120-01-07 Thread Guide On Face Plate

11-40110625-01 Screw Type Tension Stud Sm11/64x40 L=6

44-00000001-00 Safety Label

1300-01-37 Thread Tension Asm.

1300-01-38 Arm Thread Guide Plate(low)

1302-01-38 Arm Thread Guide Plate(low)

1300-01-39 Tension Releasing Pin

1300-01-40 Plug

134-02-02 Winding Thread Clamp Device Components

1300-01-55 Needle Plate

1301-01-55 Needle Plate

11-20110850-02 Screw Sm11/64x40 L=5.5

11-60112020-01 Screw Sm11/64x40 L=20

11-70113020-01 Screw Sm11/64x40 L=30

1300-01-59 Face Plate

1302-01-60D Arm

1300-01-62 Thread Take-up Lever Cover

GP-031308-00 Clamp

11-60060320-02 Screw Sm3/32x56 L=3

1300-01-54-00 Push Board Component

1281-01-14-01 Electronic Thread Clamp Device

11-80150710-01 Screw Sm15/64x28 L=7

12-61205022-01 Screw

KM2300-A1-06 Pin

1194-02-01 Winding Machine Components

11-70121020-02 Screw Sm3/16x28 L=10

134-02-03 Trimmer Knife For Winding

11-00090620-01 Screw Sm9/64x40 L=6

1300-01-49 Oilplate Of Winding Device

1300-01-50 Rubber
