2. Thread Take-up & Thread Components

Вернуться к выбору схем

Выбор схемы:

2. Thread Take-up & Thread Components

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

15

15

16

17

19

20

21

22

23

24

25

26

27

27

28

29

30

31

32-1

32

33

34

34

34

34

35

36

37

38

38

39

40

41

42

43

44

45

46

47

48

49

50

51

100%

№

Артикул Артикул и наименование

Наименование

120-02-16 Needle Bar Bushing(upper) Rubber Plugd. 8.8 L=7

120-02-15 Felt Plug

04-108A-1230 Needle Bar Bushing(upper)

1300-02-04 Needle Bar

04-103A-640L Needle Clamp

120-02-20 Thread Guide For Needle Bar

120-02-21 Needle

11-60080520-01 Needle Clamp Screw Sm1/8x44 L=4.5

11-80151550-01 Set Screw Sm15/64x28 L=15

43-10300000-00 Oil Wick

1300-02-11 Thread Take-up Lever Asm

11-60110820-01 Set Screw Sm11/64x40 L=8

120-02-25 Slide Block

120-02-23 Guide For Slide Block

11-80160710-01 Set Screw Sm1/4x40 L=7

1300-02-16 Needle Bar Crank

11-80181650-01 Set Screw Sm9/32x28 L=16

1300-02-20 Upper Shaft Front Bushing

1300-02-21 Feed Lifting Cam(left)

1300-02-22 Feed Lifting Cam Crank(left)

1300-02-23 Balance Cam

1300-02-24 Arm Shaft Bushing(middle)

11-80150810-01 Set Screw Sm15/64x28 L=8

02-121A-1230 Collar For Arn Shaft

11-80160710-01 Set Screw Sm1/4x40 L=7

25-20000000-08 Snap Ring d. 20x1. 2

1300-02-29 Feed Lifting Rod

1300-02-30 Feed Lifting Cam Crank (right)

1300-02-31 Feed Lifting Cam(right)

1302.02-32 Upper Shaft Rear Bushing(rear)

1302.02-32A Upper Shaft Rear Bushing

32-14170300-09 Oil Seal

11-80160710-01 Gear Screw Sm1/4x40 L=7

101-05-26 Bevel Gear For Arm Shaft

101-05-25 Bevel Gear For Vertical Shaft(upper)

03-102A-1230 Vertical Shaft Bushing (upper)

11-80150812-01 Set Screw Sm15/64x28 L=8

1300-02-39 Vertical Shaft

03-103A-1230 Vertical Shaft Bushing (lower)

101-05-20 Bevel Gear For Vertical Shaft(lower)

101-05-18 Bevel Gear For Hook Shaft

1302.02-44 Main Shaft

1302.02-44A Main Shaft

101-02-11 Roller Felt

12-80500612-01 Screw M5 L=6

1300-02-46-01 Fuel Lever

101-02-13 Sleeve Of Oil Amount Adjusting Pin

31-03618000-09 Rubber Ring

21-08010122-03 Washer

11-80160612-01 Screw Sm1/4x40 L=6

1302-02-51 Capstan
