Главная Каталог запчастей Запчасти для промышленных швейных машин Golden Wheel CS-299U 9. Cutting shaft pulley, cutting driving wheel cutting lever cam, cutting carrier cam, cutting shaft

9. Cutting shaft pulley, cutting driving wheel cutting lever cam, cutting carrier cam, cutting shaft

Вернуться к выбору схем

Выбор схемы:

9. Cutting shaft pulley, cutting driving wheel cutting lever cam, cutting carrier cam, cutting shaft

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

100%

№

Артикул Артикул и наименование

Наименование

548109 Cutting Shaft Pulley

548108 Cutting Shaft Pulley Oil Cup

548613 Lever Disengaging Block

545331 Screw 3/16x28L8,1

548614 Block Shim «T=0,13 Mm»

548611 Cam Groove Protector

545385 Screw 11/64x40l9,9

548491 Clamping Block

545331 Screw 3/16x28L8,1

548623 Enganging Stud Wear Plate

545331 Screw 3/16x28L8,1

548106-453 Cutting Shaft Pulley CPL

548110-453 Cutting Shaft Support Bracket

504071 Screw 3/16x28L15.1

548099-453 Cutting Shaft Hand Crank

548102 Hand Crank Stop Plunger

504051 Screw 1/8x44l5,5

548100 Position Key

545258 Screw 1/4x28L4,0

548107 Cutting Shaft Pulley Bushing

548058 Driving Wheel

545232 Screw 15/64x28L8,76

548661 Clamping Point

545314 Screw 7/64x40L6.4

548662 Spreader Cam

545314 Screw 7/64x40L6.4

548059 Driving Wheel Lock CPL

545240 Screw 3/16x28L11,1

548062 Driving Wheel Lock Stop Plate

545241 Screw 3/16x32L10,3

545242 Screw 11/64x40L6,9

548663 Driving Wheel CPL

548071 Cutting Lever «L» Cam CPL

504028 Screw 15/64x28L4,5

548074 Cutting Lever U Cam CPL

504028 Screw 15/64x28L4,5

548052 Cutting Carrier Cam CPL

548098 Cutting Shaft
