4. Механизм верхнего продвижения

Вернуться к выбору схем

Выбор схемы:

4. Механизм верхнего продвижения

Как искать запчасти?

1

2

3

3

4

5

6

7

7

7

7

8

9

9

9

10

11

12

13

14

15

16

17

18

19

19

20

21

22

23

24

25

26

27

28

28

29

29

29

29

30

30

30

31

32

33

34

35

36

37

38

39

40

40

41

42

43

44

45

46

47

48

49

50

100%

№

Артикул Артикул и наименование

Наименование

BM12-08-011 walking foot supporter guide

BM12-08-009C2 walking foot supporter bushing

BM12-08-023 screw

BM12-08-022 walking foot

BM12-08-009C1 walking foot supporter

BM12-08-020 walking foot supporter link

22T2-001A5 needle bearing

BM12-08-021 screw

BM02-08-046 nut

BM02-08-044 screw

BM12-08-019 screw

GB93 spring washer

BM02-08-048 screw nut (sm15/64" (5,95)*28)

BM12-08-018 feed connecting lever

BM12-08-010 bell crank screw

BM12-08-017D2 bell crank pin stud

BM12-08-017D1 bell crank pin

BM02-08-022 screw

BM12-08-007 feed lifting rock shaft link

BM12-08-008 bell crank

BM12-08-004B2 feed lifting rockshaft rank (left)

BM12-08-015 bell crank spring

BM12-08-014 presser regulating bracket

BM12-08-013 nut

BM12-08-012 feed regulating thumb screw

GB117 taper pin

BM12-08-006 bushing

BM12-08-003 set pin

22T3-007C2 screw

BM12-08-002 feed lifting rock shaft crank (right)

BM12-08-024 feed connecting crank rod

BM12-08-025 feed lifting eccentric

37

22T2-002 Под заказ Винт SM 5/64(5,95)*28/10 Тип.A-900 (Арт.22T2-002)

BM02-08-007 set screw

BM12-08-026 feed driving crank (right)

BM12-08-028 screw

BM12-08-027 feed driving connecting link

BM12-08-004B1 feed lifting rock shaft (upper)

BM12-08-001A1 feed driving rock shaft (upper)

BM12-08-005 feed driving shaft bushing (left)

BM02-08-041 nut

BM12-08-001A2 feed rock shaft crank (left)

BM02-08-031C2 feed connecting stud

BM12-08-016 prop up washer

BM02-08-031C1 slide block

GB896 e-type stop ring
