Запчасти для промышленного швейного оборудования

100%

№

Артикул Артикул и наименование

Наименование

BM12-02-009 needle bar connecting link guide

22T2-019 set screw

73T2-007 set screw

BN12-02-015 thread guide for needle clamp

22T5-001A4 arm shaft bushing (left)

BM12-02-014 needle clamp

BM12-02-012 Под заказ Верхняя втулка игловодителя тип. A-900 (арт. BM12-02-012)

22T1-11 set screw

BM12-02-008 needle bar connecting block

BM12-02-006 needle bar holder

BM12-02-007 set screw

BM12-02-013 needle bar

BM12-02-005 needle bar connecting link

BM12-02-003 thread take up lever crank

BM12-02-004 set screw

BM12-02-016B4 set screw

BM12-02-016B3 set screw

BM12-02-016B2 thread take up lever crank pin

BM12-02-001A1a1 Под заказ Нитепритягиватель тип. A-900 (арт. BM12-02-001A1a1)

BM12-02-001A1a5 thread take-up lever link

BM12-02-002 thread take-up lever hinge pin

BM12-02-011 needle bar bushing (upper)

BM12-02-010 felt

BM12-02-001A1a2 Под заказ Разъём тип. A-900 (арт. BM12-02-001A1a2)

BM12-02-001A1a3 Под заказ Винт SM 3/32(2,38)*56/8 Тип.A-900 (Арт.BM12-02-001A1a3)

BM12-02-016B1 crank

22T2-007 set screw

72T3-005D1a3 Под заказ Установочный винт Тип.A-797 (Арт.72T3-005D1a3)

BM12-03-003 felt

BM12-03-002 arm shaft bushing (left)

BM12-03-001 arm shaft

BM12-03-016B1 bevel gear for arm shaft

BM12-03-016B2 screw

22T5-001A4 arm shaft bushing (left)

72T1-013 screw

GB93 spring washer

BM12-03-004A3 thumb screw for feed cam

BM12-03-004A2 feed cam regulator

BM12-03-004A1 feed cam

BM12-03-008 collar

22T5-001A4 arm shaft bushing (left)

BM12-03-009 feed lifting cam

BM12-03-003 felt

BM12-03-011 arm shaft bushing (right)

BM12-03-014 set screw

BM12-03-013 balance wheel

BM12-03-015 set screw

BM12-03-010 feed lifting

BM12-03-005 feed rock shaft connecting rod

BM12-03-016B2 screw

BM12-03-017C2 vertical shaft bushing (upper)

BM12-03-017C3 vartical shaft

BM12-03-016B2 screw

BM12-03-017C6 bevel gear (lower)

BM12-03-017C5 vertical shaft bushing (lower)

BM12-04-003 felt

BM12-03-017C4 collar

BM12-04-003 felt

22T2-002 Под заказ Винт SM 5/64(5,95)*28/10 Тип.A-900 (Арт.22T2-002)

BM12-03-017C1 bevel gear (upper)

BM12-03-012 arm shaft bushing (middle)

2. Механизм игловодителя и нитепродевателя
