Главная Каталог запчастей Запчасти для промышленных швейных машин Aurora A-3500 AURORA 8. Accessory

8. Accessory

Вернуться к выбору схем

Выбор схемы:

8. Accessory

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33-2

33-6

33-3

33-4

33-5

33-1

33

34

35

36

37

38

39

40

41

42

43

44

100%

№

Артикул Артикул и наименование

Наименование

3500A001 Accessory Bag

3500A002 Driver(Large)

3500A003 Driver(Middle,Small)

3500A004 Needle(DPX17#22)

3500A005 Bobbin(Steel)

3500A006 Head Cover

3500A007 Oil Tank

3500A008 Head Hinge

3500A009 Head Hinge Rubber

3500A010 Head Hinge Rubber"A"

3500A011 Head Hinge Rubber"B"

3500A013 Head Rest

3500A014 Belt Cover "A" Ass'y

3500A015 Belt Cover "B"

3500A016 Set Screw for J-16

3500A017 Belt Cover"C"

3500A018 Belt Cover"A" "C" Connecting Screw

3500A019 Belt Cover Support Screw

3500A020 Screw(11/64" n=40)

3500A021 Screw(15/64" n=28)

3500A022 L-Wrench(2mm)

3500A023 L-Wrench(2.5mm)

3500A024 Oil Pan

3500A025 Oil Pan Gasket

3500A026 Screw(M8X1.25 )

3500A027 O-Ring for J-27

3500A028 Control Body

3500A029 Screw(3/16" n=28)

3500A030 Nut(3/16" n=29)

3500A031 Screw(15/64" n=28)

3500A032 Control Body Spring

3500A033 Knee Lifting Pad Ass'y

3500A034 Control Body Shaft

3500A037 E-Ring for J-34

3500A038 Connection Crank

3500A039 Connection Bar

3500A040 Knee Support Shaft Connectig Joint

3500A041 Screw(M6X1.0)

3500A042 Knee Support Rubber Ass'y

3500A043 Magnetic

3500A044 Bobbin Winder Ass'y

3500A045 Thread Stand Ass'y

200090007 Knee Lifting Stick Support C ap

3500A049 Spanner

3500A050 L-Wrench(5mm)

3500A051 L-Wrench(3mm)

35001040 Needle Plate
