5. Upper feed mechanism

Вернуться к выбору схем

Выбор схемы:

5. Upper feed mechanism

Как искать запчасти?

1

2

3

4

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

27

28

29

30

31

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

100%

№

Артикул Артикул и наименование

Наименование

35006001 Climb Device Adjusting Shaft

35004033 Climb Device Adjusting Shaft Bushing(Front)

35006003 Climb Device Adjusting Shaft Bushing(Rear)

200070003 Screw(11/64" n=40)

619005013 Collar for F-1

619003004 Screw(1/4", n=40)

35006007 Return Spring for F-1

35006008 Holder for F-7

35006009 Upper Feed Driving Eccentric Cam

619003004 Screw(1/4", n=40)

35006011 Upper Feed Driving Eccentric Cam Rod

35006012 Connecting Pin for F-11

35006013 Connecting Link for F-11

35006014 Up per Feed Driving Control Crank

619005008 Screw(3/16", n=28)

35006016 Connecting Shaft for F-14

GB893.1-86 C-Ring for F-16

35006018 Upper Feed Driving Connecting Link

200040013 Screw(11/64", n=40)

35006020 Upper Feed Driving Crank

200020024 Screw(15/64" n=28)

35006022 Connecting Pin for F-20

35006023 Upper Feed Driving Shaft

35006024 Upper Feed Driving Shaft Front Bus hing

35006025 Upper Feed Driving Shaft Rear Bushing

35006026 Screw(15/64" n=28)

35006027 Upper Feed Driving Rod

35006028 Upper Feed Driving Rod Wick Holder

35006029 Screw(9/64" n=40)

35006030 Hinge Screw for Upper Feed Driving Rod

35006031 Upper Feed Connecting Link

35006032 Upper Feed Connecting Link Pin

35006033 E-Ring for F-32

35006034 Upper Feed Lever Rock Crank

35006035 Upper Feed Lever Rock Crank Shaft

35006036 Screw(15/64" n=28)

35006037 Upper Feed Lever Connect ing Pin

35006038 Upper Feed Lever Driving Link H inge Screw

35006039 Nut(15/64" n=28)

35006040 Presser Bar Braket Connect ing Link

35006041 Hinge screw for F-40

35006042 Pin for F-40

35006043 Upper Feed Presser F oot

35006044 Upper feed lever

45

35006045 В наличии мало (на удаленном складе) Винт тип. Aurora A-0302 / 0302E / 0302ECX / 0302ECX-L и аналоги (арт. 35006045)

35006046 Upper Feed Lever Level D riving Rod

35006047 Upper Feed Lever Level Driving Shaft C rank (Rear)

200020024 Screw(15/64" n=28)

35006049 Hinge Screw Fo r Upper Feed Lever Level Driving Shaft Crank (Rear)

330010049 Nut(9/32" n=28)

35006051 Upper Feed Lever Level Driving Shaft

35004092 Upper Feed Lever Level Driving Shaft Front Bushing

200030003 Screw (15/64", n=28)

35006054 Upper Feed Lever Level Driving Shaft R ear Bushing

200030003 Screw (15/64", n=28)

35006056 O-Ring for F-51

35006058 Climb Device Eccentric Cam Top Cover

59

35006057 Под заказ Деталь регулятора стежка (А-0302) (арт. 35006057)

35006060 Climb Device Eccentric Cam(Arm)

35006061 Screw(11/64" n=40)

35006062 Pin for F-57, F-59

35006063 Spring for F-62

35006064 Climb Device Dial Support Ring

35006065 Upper Feed Level

35006066 Screw(15/64" n=28)

330010058 Upper Feed Level Adjusting Shaft

68

330010060 Под заказ Соединительная гайка тип. Aurora A-0302 / 0302E / 0302ECX / 0302ECX-L (арт. 330010060)

330010059 Block

200040010 E-Ring fo r F-67

35006072 Upper Feed Level Driving Link

35006073 Hinge Shaft for F-72

35006074 Set Screw for F-7 2

200030010 Screw(15/64" n=28)

35006076 Upper Feed Lever Level Adjusting Crank

35006077 Hinge Screw for F-76

35006078 Upper Feed Level Holder

200062005 Screw(9/64" n=40)

35006080 Upper Feed Lever Support Plate

3300 Upper Feed Lever Support Plate Ring

81

200050017 Под заказ Винт крепления установочного пальца SM4.37X9мм тип. Aurora A-721, Brother B721 (арт. 200050017; 107407003)

35006083 Frame for Upper Feed Pressure Adjusting Screw

200044005 Screw(11/64" n=40)

330010053 Screw(9/32" n=28)

330010054 Nut(9/32" n=28)

330010049 Upper Feed Pressure Adjusting Spring

35006088 Upper Feed Pressure Adjusting Spring Bar

35006089 Fulcrnm for F-87

35006090 Fulcrnm for F-88

35006091 Hinge Screw for F-90

35006092 Needle Bar Safety Guide
