Главная Каталог запчастей Запчасти для промышленных швейных машин Aurora A-252 AURORA 1. Корпус машины

1. Корпус машины

Вернуться к выбору схем

Выбор схемы:

1. Корпус машины

Как искать запчасти?

1

2

3

4

5

6

7

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

100%

№

Артикул Артикул и наименование

Наименование

GQ106 body uper segment

GS136 body screw (m30x35-4 socket head cap screw)

GK212 panel board catching plate

GS133_1 catching plate screw (m5x12-2, m5x20-1 socket head cap screw)

GKS103_1 footstep lever screw

GS132_1 panel screw (m4x16-2 socket head cap screw)

GS132_2 panel screw (m4x16-4 socket head cap screw)

GKS104 panel iii

GS132_3 panel screw (m4x16-2 socket head cap screw)

GKS207 oil catching plate

GS131_1 oil catching plate screw (m3x10-1, m3x6-2 socket head cap screw)

GK208_1 side panel

GS134_1 side panel screw (m3x10-2 socket head cap screw)

GKS102_1 side back cover

GS132_4 side back cover screw (m4x40-2 socket head cap screw)

GK202 back cover plate

GS123_1 back cover plate screw (m5x9.5-2 plain screw)

GX101 threading screw

GK201_1 upper cover plate

GS122_1 oil box screw (m4x12-2 plain screw)

GS123_2 upper cover plate screw (m5x9.5-2 plain screw)

GS134_2 belt hood screw (m6x60-2 socket head cap screw)

GK201_2 belt hood washer (ф6x1.5-2)

GKS100 belt hood 1

GO100 belt hood screw saddle (ф10хф6.2х40-2)

GL204_1 belt hood nut

GS122_2 belt hoodd 2 screw (m4x7.5 plain screw)

GKS101 belt hood 2

GK200 belt hood support

GS134_3 belt hood screw

GS134_4 angle stand screw (m6x12-2 socket head cap screw)

GK199 angle stand

GS172_1 connection board screw (m5x8-2)

GK206 connection board

38

GM-107 В наличии (на удаленном складе) Игольная пластина тип. Aurora A-252 (арт. GM-107)

GS172_2 faller screw (m5x8-2)

GK205 push pedal

GW100 push pedal spring

GK209A small oil seal

GK209B small oil seal without station

GK208_2 big oil seal

GK210 oil pipe joint

GX102 pendulum stand spacing pin 1

GX103 pendulum stand spacing pin 2

GS121_1 push board spring screw (m3x4-2 plain screw shim ф6.8хф3.2х0.5-2)

GKS105 stitch cover board

GS134_5 stitch cover board screw (m6x16-2 socket head cap screw)

GS132_5 drawing stand screw (m4x18-i socket head cap screw)

GS131_2 catching oil plate screw (m3x10-1 socket head cap screw)

53

GXR222 Под заказ Петля Тип.A-450 (Арт.GXR222)

GS145_1 countersunk screw (m8x20-4)

GS112_1 top wire of pendulum stand spacing pin (m6x6 grub socket head cap screw)

GS113_1 top wire of pendulum stand spacing pin 2 (m5x8 grub socket head cap screw)
