17. Механизм триммера нижней нити

Вернуться к выбору схем

Выбор схемы:

17. Механизм триммера нижней нити

Как искать запчасти?

1-3

1-2

1-5

1-4

1-1

1

2

3

4

5

10-3

10-2

10-1

10-4

10

11

12

16

17-2

17-1

17

18

19

20

21

22

23

24

25

26

27

28

29

30-4

30-3

30-5

30-2

30-1

30

30

31

32

33

34

35

36

37

38

39-6

39-5

39-3

39-2

39-4

39-1

39

40

41

42-2

42-1

42

43

49

50

51

52-2

52-1

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66-2

66-3

66-1

66

66

66

100%

№

Артикул Артикул и наименование

Наименование

S51171001 cam lever assy_ ;l-tr

S50246001 cam lever_ ;l-tr

107744001 roller

141519001 roller stud

110161004 Гайка (Арт. 110161004)

048030342 retaining ring_ e3

S51170001 lower thread trimmer cam assy

S50247001 lower thread trimmer cam

S50411001 roller, d-lever

145478101 shoulder screw_ m4.76

S50248001 connectin rod, l-tr

150491101 lever shaft

014760622 set screw, socket sm5.95

159269001 lower thread cutting link stud screw

S50249001 link assy, l-tr

S59987001 connecting rod, a

062680512 screw 4.37x5

159267001 lower thread cutting cam shaft 0703b

110494001 washer

149127001 stud screw 6.35

S50252001 knife driving lever

113730001 stud screw 4.37

159272001 movable knife driving lever stud screw

S00903001 collar 0703b

S00901001 washer (u)

S00902001 washer (d) 0703b

S50253001 lever assy

S50257001 collar

S00712101 screw 4.37

S50258001 lower thread retainer

110215002 screw sm3.57

S50259101 fixed knife set

S50260101 lower fixed knife assy

S50263001 movable knife

S50264000 washer

025040132 washer 4

060630312 screw_ bind sm2.38x3

048080342 stop ring e8

014760622 set screw, socket sm5.95

060670412 screw_ bind sm3.57x4

32

S50265001 Под заказ Пластина прижимная тип. Brother HE-800 (арт. S50265001)

025040132 washer 4

S50269000 washer

S50270000 lower thread presser

145371001 stud screw 2.38

110215002 screw sm3.57

S52432001 opening plate assy

S52433001 opening plate, a

110167001 roller

110168001 roller stud

S52434001 opening plate_ b

39-5

141514001 Под заказ Винт Тип.Screw (Арт.141514001)

123185001 screw 3.57x4.5

149127001 stud screw 6.35

105970001 screw 2.38

S52778001 base plate assy

S50303001 bale plate

S52770000 cover, b-plate

106629002 screw_ sm4.37

S01696001 screw 3.57x6

S50323000 bobbin presser

S01998001 screw 3.57

S51172001 bobbin presser bracket assy

S50324001 bobbin presser bracket

107639001 spring hook

159924001 presser stop lever stud screw 0703b

062671612 screw 3.57x16

062680512 screw 4.37x5

S50325001 auxiliary plate

S50326001 opening plate

105237002 stud screw 3.57

159113001 shoulder screw, sm3.18

159379001 grooved pin 6x18

S50327001 spring_ extension

S50328001 spring_ plate

159379001 grooved pin 6x18

S50329000 cover

S51248101 needle plate_ 1.2s-3

S50664001 needle plate, 1.4s (for -2)

S51248101 needle plate_ 1.2s-3

S54522001 needle plate. 1.4-50
