Главная Каталог запчастей Запчасти для промышленных швейных машин Aurora A-781, 782, 783 AURORA 1. Frame & miscellaneous cover components (1)

1. Frame & miscellaneous cover components (1)

Вернуться к выбору схем

Выбор схемы:

1. Frame & miscellaneous cover components (1)

Как искать запчасти?

1

2

3

4

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

34

35

36

37

37

38

39

40

41

42

43

44

44

44

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

100%

№

Артикул Артикул и наименование

Наименование

B1137-771-000 Frame Side Cover B

B1137-771-00A Frame Side Cover B

SS-4111015-SP Screw 11/64-40 L=10

WP-0450000-SD Washer 4,5x8x0,5

CM-3002001-01 Safety Label 1 (Small)

SS-4111015-SP Screw 11/64-40 L=10

400-09028 Arm Support Rod

SS-8110510-SP Screw 11/64-40 L=5

B1120-761-000 Pin

B1118-761-000 Rubber Cushion

B1116-771-000 Side Cover (C)

400-09010 Arm Side Cover (C)

B1152-771-000 Side Cover Gasket (C)

SS-4110915-SP Screw 11/64-40 L=9

B1138-771-000 Frame Side Cover (C)

B1138-771-00A Frame Side Cover (C)

SS-4112215-SP Screw 11/64-40 L=22

SS-4111415-SP Screw 11/64-40 L=14

B1155-771-000 Cushion

B1144-771-000 Frame Side Cover Gascet (C)

B1153-781-000 Left Side Cover

400-08995 Left Side Cover

B1145-771-000 Side Cover Gasket

SS-4110915-SP Screw 11/64-40 L=9

B1123-581-000 Thread Take-Up Lever Oil Guard

400-09039 Thread Take-Up Lever Cover

SS-4090515-SP Screw 9/64-40 L=5

B1112-771-0A0 Face Cover Complete

B1112-771-0AA Face Cover Complete

B1149-771-000 Gasket

B1151-771-000 Face Plate Gasket (B)

SS-4111415-SP Screw 11/64-40 L=14

SS-4110915-SP Screw 11/64-40 L=9

TA-1250705-R0 Rubber Plug

B1103-771-000-A Top Cover

B1103-771-00A Top Cover

B1106-771-000 Worm Gear Shaft Metal

100-04109 Ground Mark

SS-6120620-TP Screw

B1110-771-000 Top Cover Gasket (Front)

B1117-771-000 Oil Felt

B1254-781-000 Main Shaft Thrust Seel

SS-4111815-SP Screw 11/64 L=18

TA-0750704-R0 Rubber Plug

B1106-761-000 Gear Case Cover

400-09030 Gear Case Cover

B3125-155-000 Disk Spring

SD-0640261-SP Hinge Screw D=3,65 H=2,6

SS-7111310-SP Screw 11/64-40 L=12,8

B2926-771-000 Hand Stop Latch

SS-4110715-SP Screw 11/64-40 L=7

400-09038 Ball Screw

NS-6120310-SP Nut 3/16-28

TA-2101002-R0 Rubber Plug

B1104-771-000 Top Cover Gasket (Rear)

B3558-771-000 Arm Oil Shield

SS-4110715-SP Screw 11/64-40 L=7

B2743-771-000 Knife Stop Lever Shaft Guide

TA-1050504-R0 Rubber Plug

B1111-771-000 Side Cover (A) Gasket

B1114-771-000 Side Cover (A)

400-09008 Arm Side Cover (A)

SS-4110915-SP Screw 11/64-40 L=9

B1133-771-000 Oil Sight Window Gasket

B1115-771-0A0 Side Cover Asm. B

400-09009 Arm Side Cover (B)

SS-4110915-SP Screw 11/64-40 L=9

B1128-771-000 Side Cover (A)

B1128-771-00A Side Cover (A)

SS-4111015-SP Screw 11/64-40 L=10

WP-0450000-SD Washer 4,5x8x0,5

CM-3002001-01 Safety Label 3 (Small)

400-09034 Bed Slide

400-09036 Bed Screw Stud A

400-09363 Bed Oil Shield Asm.

400-09384 Bed Oil Shield Stud

SS-4110515-SP Screw 11/64-40 L=5

CM-3002000-B1 Label (16)

CM-3002000-01 Attention Seal

400-09014 Oil Sight Window
