Главная Каталог запчастей Запчасти для промышленных швейных машин Aurora А-2628 AURORA 1. Arm bed and its accessories

1. Arm bed and its accessories

Вернуться к выбору схем

Выбор схемы:

1. Arm bed and its accessories

Как искать запчасти?

1

2

3

4

5

6

7

8

9

10

11

12

13

14

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

50

50

51

52

53

54

55

56

57

58

59

100%

№

Артикул Артикул и наименование

Наименование

05-01-001A2 Arm

09-01-001-B2 Arm. Bed

09-01-002 Trade Mark Plate

GB827-86 Trade Mark Plate Rivet

05-01-003 Face Plate

05-01-004 Set Screw

05-01-005 Knock Pin

05-01-006 Thread Guide (Up)

22T1-003C5 Thread Guide (Middle)

05-01-013 Thread Guide (Lower)

22T1-003C6 Set Screw

05-01-014 Arm Side Cover

05-01-015 Gasket For Arm Side Cover

72T1-017 Set Screw

12H1-007C1 Oil Check Window

12H1-007C2 O-Ring

22T1-009E Pretension Thread Guide Asm.

22T1-009E Pretension Thread Guide Asm.

22T1-009E Pretension Thread Guide Asm.

22T1-009E Pretension Thread Guide Asm.

22T1-009E Pretension Thread Guide Asm.

22T1-009E Pretension Thread Guide Asm.

22T1-010 Three-Hole Thread Guide

22T1-011 Set Screw

05-01-007C1 Thread Tension Bracket

05-01-007C2 Thread Tension Stud

05-01-007C3 Tension Regulating Nut

73T1-002C1 Thread Tension Spring

05-01-007C4 Thread Tension Releasing Disc

05-01-007C5 Thread Tension Disc

05-01-007C6 Stop Disc

05-01-007C7 Pin

05-01-007C8-1 Thread Controller Disc

05-01-007C8-2 Thread Controller Plate

05-01-007C9 Screw

05-01-007C10 Thread Tension Release Plate

05-01-007C11 Screw

05-01-007C12 Thread Tension Release Pin

05-01-008 Thread Controller Stud

05-01-009 Thread Take-Up Spring

05-01-010 Tension Thumb Nut

05-01-011 Thread Take-Up Spring Stop

05-01-016 Screw

22T1-011 Set Screw

01-01-006 Bed Side Cover

01-01-007 Gasket For Bed Side Cover

72T1-017 Set Screw

09-01-003 Cap For Bed Face Plate

72T1-004C4 Rubber Plug 11.8

72T1-009 Rubber Plug 8.8

72T1-011 Rubber Plug 5.7

09-01-004 Bed Cover

09-01-005 Gasket For Bed Cover

09-01-006 Bed Rear Cover

09-01-007 Gasket For Bed Rear Cover

72T1-017 Set Screw

72T1-017 Set Screw

22T1-011 Set Screw
